• Rated current from 20~90 A
• Coil voltages from 24~600 Vac, 50/60 Hz
• Coil is Class H 180 ºC (356 ºF)
• Available with enclosed coils for protection against particle contamination
• 1, 2, 3 and 4 pole configurations
• Industry standard mounting plate provides easily accessible mounting holes
• More connection terminal options, including screw or lug connections each with quick connect spades
• Double E magnet assembly provides optimal performance with reduced power consumption
• 1NO+1NC auxiliary contact block with 600 Vac available as an option
• Base assembly is made from high arc-resistant polyester
