• Complete Power Blocks range, from 80A up to 630A IEC® – 85A up to 545A UL®
• Offer multiple connection possibilites with One cable, Two cables or ERICO® FLEXIBAR® and IBSB/IBSBR Power Braid
• Large cross section aluminum/ copper conductor connection
• Offer time savings and reliability
• High short-circuit current rating
  – 100kA SCCR (UL)
  – lpk up to 51kA (IEC)
• High voltage values under IEC & UL certification (minimum of 1000V AC/DC)
• Modular: individual modules are stackable for multiple applications

Click here for Distribution Blocks, Power Blocks and Power Terminals Catalogue (13.4 MB)

• Tinned Copper Block : Copper or Aluminum Cables
• Visual inspection of wire and confi rmation of connection
• Quick connection with studs or tunnel
• Easy connection on ERICO® FLEXIBAR® or Cable
• Adjustable transparent cover
• Halogen Free
• Self extinguishing: UL94 V-1
• Easy fixing: clip on din rail with end cap or mount to panel with screws
• Short Circuit Rated up to 100 KA – See UL® fi le E198301
• RoHS Compliant

Click here for Distribution Blocks, Power Blocks and Power Terminals Catalogue (13.4 MB)
